SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig

Basic Information
Place of Origin: China
Brand Name: VESON
Certification: ISO CE
Minimum Order Quantity: 1
Price: Fob Shanghai ,EXW
Packaging Details: plywood case with reforinced packing
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 10000
Detail Information
Butterfly Valve: Wafer Type Type: Double Acting Or Spring Return
Name: Air Operated Butterfly Valve Pressure Range: 25mm - 200mm: 16 Bar 250mm - 300mm: 10 Bar
Temperature Range: -50oC To 120oC Application: Marine Industry
Valve Plate: Alum Brz Certification: ABS
High Light:

SS316 Actuated Butterfly Valve

,

Marine Actuated Butterfly Valve

,

Rig Air Operated Butterfly Valve


Product Description

SS316 Pneumatic Butterfly Valve Air Operated For Marine Industry


Pneumatic actuator


Material Stainless Steel, SUS304, SUS316, SUS316L
Rotary Angle 0~90 degree
Structure rack and pinion rotary actuator
Working Pressure 2~8bar
Surface Treatment hard anodizing
Working Temperature Normal Temperature: -20ºC(-4°F) ~ 80ºC (+176°F);

High Temperature: -20ºC(-4°F) ~ 150ºC (+302°F);

Low Temperature: -40ºC(-104°F) ~ 80ºC (+176°F).
Connection NAMUR, ISO5211, and DIN3337
Application ball valve, butterfly valve, and rotary machine
Cup Color STEEL







Butterfly  valve Sizes:
DN 40 – DN 1200 (1½” ~ 48″)
DN 1400 – DN 2000 (56″ ~ 80″) (other sizes on request)

Flange connection:
EN1092 (PN 6-10-16, PN25 up to DN 400)
ASME B 16.5 (class 150 – 300)
JIS B 2239 & 2220 (5K, 10K, 16K, 30K)

Temperature range -23°C to +200°C
Short face to face acc. EN 558-1 row 20
Top flange acc. EN ISO 5211



SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 0SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 1

SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 0



SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 3


SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 4



SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 5

SS316 Actuated Butterfly Valve Alum Brz Plate Air Operated For Marine Rig 3
