Double-Flanged ANSI 150lb Butterfly Valve Expertly Designed with PTFE Seat Remote Gear Transmission System
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | VESON |
| Certification: | ISO 9001:2015 SGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Price: | USD 150-3500 / Piece |
| Packaging Details: | VESON branded plywood case with shock-proof foam insert, export-grade packaging |
| Delivery Time: | 3-5 working days for stock, 15-25 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 3000 Pieces per Month |
|
Detail Information |
|||
| Valve Type: | Double-Flanged Butterfly Valve | Size Range: | DN50 To DN500 (2" To 20") |
|---|---|---|---|
| Pressure Rating: | ANSI 150lb (PN16) | Body Material: | Ductile Iron Epoxy Coated / SS316 |
| Disc Material: | PFA-Lined Ductile Iron / SS316 / Hastelloy | Seat Material: | PTFE / RTFE |
| Operation: | Remote Gear Transmission With Floor Stand | Flange Standard: | ANSI B16.5 Class 150, Flanged Ends |
| Certificate: | ISO 9001:2015, SGS | Application: | Chemical Processing, Acid Handling, Corrosive Media |
| Highlight: | Double-Flanged Butterfly Valve,PTFE Seat Chemical Service,Remote Gear Transmission |
||
Product Description
Double-Flanged ANSI 150lb Butterfly Valve with PTFE Seat for Chemical Service
The VESON Double-Flanged ANSI 150lb Butterfly Valve with PTFE seat is purpose-built for chemical processing applications requiring full corrosion resistance. The double-flanged body design enables easy installation and removal from the pipeline, while the PTFE seat and PFA-lined disc provide universal chemical compatibility for aggressive acids, solvents, and corrosive media.
Key Features
- Double-Flanged Design: Flanged ends on both sides for secure bolted installation with full gasket sealing, ideal for critical chemical lines
- PTFE Seat: Universal chemical resistance with wide pH range (0-14) and temperature stability to +180°C
- PFA-Lined Disc: Fully encapsulated disc eliminates metal-to-media contact for maximum corrosion protection
- Remote Gear Transmission: Floor-stand mounted gear operator with extended spindle for safe operation away from chemical exposure zones
- Blowout-Proof Stem: Anti-blowout stem design meets API 609 requirements for enhanced personnel safety
Technical Specifications
| Parameter | Specification |
| Valve Type | Double-Flanged Butterfly Valve |
| Size Range | DN50 to DN500 (2" to 20") |
| Pressure Rating | ANSI 150lb (PN16) |
| Body Material | Ductile Iron Epoxy Coated / SS316 |
| Disc Material | PFA-Lined Ductile Iron / SS316 / Hastelloy |
| Seat Material | PTFE / RTFE |
| Stem Material | SS316 / Hastelloy C276 |
| Operation | Remote Gear Transmission with Floor Stand |
| Flange Standard | ANSI B16.5 Class 150 |
| Operating Temperature | -40°C to +180°C |
| Certificate | ISO 9001:2015, SGS |
Target Applications
- Sulfuric acid dilution and transfer
- Hydrochloric acid handling systems
- Solvent and monomer transfer lines
- Chemical tank farm isolation
- Chlor-alkali process piping
Each valve undergoes full factory hydrostatic and pneumatic seat testing. Complete chemical compatibility data and material certificates available upon request.
