3 Position Pneumatic Actuator with ISO 5211 Flange and 3 Position Control for Valve Automation with 10-500 Nm Torque Range
Product Details:
Get Best Price Contact Now|
Detail Information |
|||
| Material: | Aluminum Alloy | Responsetime: | 0.1-0.5 Seconds |
|---|---|---|---|
| Actuatortype: | Pneumatic | Torquerange: | 10-500 Nm |
| Connectiontype: | ISO 5211 Flange | Controltype: | 3 Position Control |
| Sealmaterial: | NBR (Nitrile Rubber) | Mountingtype: | NAMUR Standard |
| Highlight: | 3 position pneumatic actuator for valves,high demand valve automation actuator,pneumatic actuator for valve automation |
||
Product Description
Valve Automation 3 Position Pneumatic Actuator
The 3 Position Pneumatic Actuator is a highly reliable and efficient device designed specifically for valve automation applications. Utilizing compressed air to generate mechanical motion, it provides precise and robust control of valve positions with three distinct positioning points for enhanced operational flexibility and process control.
Featuring quarter turn functionality, this actuator rotates valve shafts by 90 degrees, making it essential for operating ball valves, butterfly valves, and plug valves. The quick and precise valve positioning ensures optimal flow control in various industrial processes.
Constructed with high-quality materials including NBR (Nitrile Rubber) seals, the actuator offers excellent resistance to wear, oil, and chemicals. This ensures airtight performance, consistent operation, and low maintenance requirements in demanding environments.
The actuator seamlessly integrates with Electro Pneumatic Positioners for accurate positioning based on control system commands, enhancing system accuracy, responsiveness, and efficiency while providing valuable feedback for real-time monitoring and diagnostics.
Key Features
- 3 Position Pneumatic Actuator with precise control for multi-position applications
- Double Acting Pneumatic Actuator design for reliable and efficient operation
- Connection type: ISO 5211 Flange for easy and standardized mounting
- Torque range from 10 to 500 Nm, suitable for various valve sizes and requirements
- Surface treatment: Anodized finish for enhanced durability and corrosion resistance
- Mounting type: NAMUR Standard, compatible with a wide range of accessories
- Equipped to integrate with Electro Pneumatic Positioner for precise positioning and control
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | 3 Position Pneumatic Actuator |
| Torque Range | 10-500 Nm |
| Positions | 3 |
| Seal Material | NBR (Nitrile Rubber) |
| Surface Treatment | Anodized |
| Mounting Type | NAMUR Standard |
| Application | Valve Automation |
| Control Type | 3 Position Control |
| Connection Type | ISO 5211 Flange |
| Response Time | 0.1-0.5 Seconds |
Applications
The 3 Position Pneumatic Actuator provides precise control in various industrial automation applications including oil and gas, chemical processing, water treatment, power generation, food and beverage manufacturing and HVAC systems.
Its ISO 5211 flange connection ensures secure mounting, while the quarter turn functionality allows rapid 90-degree rotation for swift switching between open, closed, and intermediate positions. The NAMUR standard mounting type facilitates compatibility with accessories like solenoid valves, limit switches, and positioners.
Customization Options
Crafted from high-quality aluminum alloy, our 3 Position Pneumatic Actuator offers durability and lightweight performance. We provide customization services to integrate advanced Electro Pneumatic Positioners, enhancing accuracy and reliability.
Custom specifications for material, response time, or control system integration ensure optimal performance tailored to your unique valve automation requirements.
Support & Services
We provide comprehensive technical support including installation guidance, troubleshooting, and maintenance tips to ensure optimal actuator performance. Our services include custom modifications, performance testing, and training sessions for maintenance personnel.
For detailed product manuals, software updates, and FAQs, please refer to our online resource center. We are committed to providing timely and effective support for your pneumatic actuator needs.
Frequently Asked Questions
Q1: What is a 3 Position Pneumatic Actuator?
A 3 Position Pneumatic Actuator is a device that controls valve movement using compressed air, positioning the output shaft in three distinct positions for more precise control compared to standard two-position actuators.
Q2: What are the typical applications of a 3 Position Pneumatic Actuator?
This actuator is commonly used in industrial automation, HVAC systems, water treatment plants, and manufacturing processes where precise valve positioning is required to regulate flow, pressure, or other parameters.
Q3: What materials are used in the construction of the actuator?
The actuator is typically made from durable materials such as anodized aluminum for the body and stainless steel for internal components, ensuring corrosion resistance and long service life in various environments.
Q4: What kind of control signals does the 3 Position Pneumatic Actuator support?
It supports pneumatic control signals for positioning, often combined with electrical feedback sensors for monitoring the actuator's position in real time, enabling integration with automated control systems.
Q5: How do I install the 3 Position Pneumatic Actuator?
Installation involves mounting the actuator onto the valve using provided brackets and coupling, connecting to a compressed air supply and control system according to manufacturer guidelines for proper operation.
