Multi-Port Pneumatic Ball Valve Package Solution Designed for Chemical Reactor Feed Switching Tank Farm
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | VESON |
| Certification: | ISO 9001:2015 SGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Price: | USD 200-1500 / Piece |
| Packaging Details: | VESON brand or customer brand plywood case with shock-proof foam insert, export-grade packaging |
| Delivery Time: | 5-7 working days for stock, 20-30 days for production |
| Payment Terms: | T/T,L/C,PayPal,Western Union |
| Supply Ability: | 2000 Pieces per Month |
|
Detail Information |
|||
| Valve Type: | 3-Way Multi-Port Ball Valve (L-Port / T-Port) | Actuator Type: | Double-Acting Pneumatic Rack & Pinion |
|---|---|---|---|
| Size Range: | DN15 To DN150 (1/2" To 6") | Pressure Rating: | PN16 / PN40 / Class 150 / Class 300 |
| Body Material: | SS304, SS316, WCB Carbon Steel | Ball Configuration: | L-Port (90° Switching) Or T-Port (180° Mixing/diverting) |
| Seat Material: | PTFE, RTFE, PEEK | Air Supply: | 4-8 Bar (60-120 Psi) |
| Operating Temperature: | -20°C To +180°C | End Connection: | Flanged ANSI B16.5, Threaded NPT/BSP |
| Highlight: | Multi-Port Pneumatic Ball Valve,Double Acting Pneumatic Ball Valve |
||
Product Description
Multi-Port Pneumatic Shutoff Ball Valve Package for Reactor Feed Switching & Tank Farm Manifold
The VESON Multi-Port Pneumatic Shutoff Ball Valve Package is designed to replace complex multi-valve manifolds with a single integrated unit. Available in L-Port (90° switching) and T-Port (180° mixing/diverting) configurations, this package significantly reduces skid footprint, piping complexity, and potential leak paths in chemical reactor feed systems and tank farm manifolds.
Manifold Reduction Benefits
| Traditional Setup | VESON Multi-Port Solution |
| 3 x 2-Way Valves + Tees + Piping | 1 x 3-Way L-Port Valve Package |
| 4 x 2-Way Valves + Cross + Piping | 1 x 3-Way T-Port Valve Package |
| Multiple actuators, solenoid valves, limit switches | Single actuator, solenoid, limit switch set |
Key Features
- L-Port Configuration: 90° rotation switches flow between two independent circuits (Port A ↔ B or Port A ↔ C)
- T-Port Configuration: 180° rotation for flow mixing (all three ports connected) or diverting (any two-port combination)
- Single Actuator Operation: One double-acting pneumatic actuator controls all port switching, reducing automation hardware by up to 60%
- Reduced Leak Paths: Eliminates multiple flange connections and weld joints, minimizing fugitive emissions risk
- Compact Footprint: Typical skid space savings of 40-50% compared to multi-valve manifold arrangements
- Factory Pre-Assembled: Complete package arrives pre-tested and ready for installation, reducing field commissioning time
Technical Specifications
| Parameter | Specification |
| Valve Type | 3-Way Multi-Port Ball Valve |
| Ball Configuration | L-Port (90° two-way switching) / T-Port (180° three-way) |
| Actuator Type | Double-Acting or Spring-Return Pneumatic Rack & Pinion |
| Size Range | DN15 to DN150 (1/2" to 6") |
| Pressure Rating | PN16 / PN40 / Class 150 / Class 300 |
| Body Material | SS304, SS316, WCB Carbon Steel |
| Seat Material | PTFE, RTFE, PEEK |
| Air Supply | 4-8 bar (60-120 psi) |
| Operating Temperature | -20°C to +180°C |
| End Connection | Flanged (ANSI B16.5), Threaded (NPT/BSP) |
| Shutoff Class | Class VI (Bubble-Tight) |
| Certification | ISO 9001:2015,, SGS |
Target Applications
- Chemical reactor feed switching (raw material A vs B vs C)
- Duplex filter backwashing skids (duty/standby switching)
- Tank farm product transfer manifolds
- Custody transfer metering skids
- Heat exchanger bypass and diversion systems
Factory pre-assembled with SS316 hard tubing, fully loop-tested, and delivered with complete material certificates and FAT documentation. Contact our engineering team for L-Port vs T-Port selection guidance.
