Aluminum Alloy Pneumatic Air Actuator , Double Acting Actuator Ptfe Coated

Product Description

SIlicone Seal Double Acting Pneumatic Actuators For High / Low Temperature PTFE Coated

Veson valve ltd 3 position pneumatic actuators provide an operation of 0°- 45°- 90°. The intermediate position is achieved by an external mechanical stop of movement on the 2 auxiliary pistons (for spring return actuators it may be only one auxiliary piston).

 This intermediate stop position is adjustable from 0° to 90°, for example 5°, 20°, 30° 50°, 75° etc. The intermediate position is easily achieved by adjusting the external nuts located outside the two end-caps. Both type, double acting and spring return, are available. Field of application: For dosing, for exact filling and for any kind of services where on 90° rotation an intermediate stop position is desired

Pneumatic actuator accessories include:

• switches
• solenoids
• pilots
• quick exhausts
• volume boosters
• flow control valve
• speed controls
• bug screens
• mufflers
• manual block and vent

  Parameter/Performance	Description
  Type	Veson Pneumatic actuator
  Actuation Method	Air pressure
  Operating Pressure	80-120 psi
  Operating Temperature	-20°C to 80°C
  Rotation Angle	0-90°, 0-180°, or 0-360°
  Torque Output	10-10,000 Nm
  Body Material	Aluminum alloy, stainless steel, or carbon steel
  End Connection	Flanged, threaded, or welded
  Position Indicator	Visual or electronic
  Control Signal	3-15 psi or 4-20 mA
  Response Time	0.1-0.5 seconds
  Life Cycle	1 million cycles or more

Contact Veson valve ltd. sales@veson-valve.com for more details.
