Pneumatic Shutdown valve scotch yoke penumatic actuator ball valve

Basic Information
Brand Name: ASCO
Model Number: 8320/ G174, G176, G186
Minimum Order Quantity: 1
Packaging Details: cartoon case with reforinced packing
Delivery Time: 5-8days
Payment Terms: L/C, T/T
Supply Ability: 100
Detail Information
Voltage: 24VDC 220VAC Rating:: Explosion-proof
Material:: SS/ Brass Product Name: Pneumatic Valve Accessories
Fuction: Flow Control
High Light:

automatic water shut off valve


pneumatic emergency shut off valve

Product Description


Pneumatic Plug Valve
1.Size:1/2"~24" DN15~DN600
2.Pres: 150lb~900lb,PN20~PN150
3. Stru: Sleeve type / Three way / Four way

Pneumatic Plug Valve

3-way, four way plug valve is applicable to change the media flowing direction or to distribute the media, that are used in various industries. such as: petroleum, chemical industry, pharmacy.

Chemical fertilizer, power, industry etc. Under nominal pressure class 150lb~900lb, PN1.0~16.0

Working temperature -29 °C~550 °C.

Structure Feacture

1. The product has reasonable structure, reliable sealing, excellent performance and beautiful appearance.

2.According to different conditions, the 3 way , 4 way plug valve can be designed into multiple media flowing forms(eg. “L” type or “T” type ) or all kinds of material (eg. Iron, cast steel , stainless steel ) or unlike sealing type (eg. Metal to metal , sleeve type , lubricated type etc.)

3.The materials of parts and sizes of flanges can be reasonably configured according the actual operating condition of the requirements of the customers, so as to meet various needs of engineering.

4. Driving manner: Wrench , Worm., Worm gear pneumatic, electric- actuated.

Standard reference


1.Design and manufacture standard API6D
2.Face to face dimension standard ASME B16.10
3.Flange connetion standard ASME B16.5
4.Test and inspection standard API 598, API6D

Material for main parts

Body Cast Iron,WCB,WC1,WC6,WC9,C5,CF8,CF8M,CF3,CF3M etc.
Plug A182-Gr.F6a, A182-F22. A182-F304 ,F316,F321,F304L,F316
Stem ASTM A182-Gr.F6a,ASTM A182-F22,ASTM A182-F304, F316,F321,F304L.F316L.
Packing PTFE. Flexible graphite
Cover WCB,WC1,WC6,WC9,C5,CF8,CF8M,CF3,CF3M
